1550nm EML Transmitter
Distance up to 40km over SMF
Single 3.3V Power supply and TTL Logic Interface
Duplex LC Connector Interface
Hot Pluggable
Power Dissipation < 1.5 W (Typical < 1W)
Dispersion Tolerance 800ps/nm
Operating Case Temperature Standard : 0°C to +70°C
Compliant with SFF-8431 MSA
Compliant with SFF-8432 MSA
Compliant with SFF-8472 MSA
Compliant with IEEE 802.3ae
